Patrol Vehicle II X100C
Description
Features:
Product Value
1. Fast response: response time ≤ 100ms
2. Efficient iteration: 100% line control parts FOTA
3. Precise execution: response accuracy higher than 10% of the industry
4. High stability: safe driving 3 million kilometers
Functional highlights
1. Multiple supplemental energy modes
2. Various control forms
3. Standard can protocol communication
4.Active and passive safety strategy
Parameters
| Category | X100C |
|---|---|
| Length (mm) | 2158 |
| Width (mm) | 960 |
| Height (mm) | 560 |
| Wheelbase | 1250 |
| Curb Weight (kg) | 400 |
| Max Gross Vehicle Weight (kg) | 1000 |
| Chassis Range (km) | 100 |
| Max Grade Climbing (fully loaded) | 20 |
| Top Speed on Flat Road (km/h) | 40 |
| Minimum Turning Radius (m) | 2.8 |
| Minimum Ground Clearance (mm) | 130 |
| Water Depth (mm) | 100mm at 15km/h |
| Operating Temperature (°C) | -25~55 |
| Waterproof Rating | IP55 |
| Voltage Platform (V) | 60 |
| Charging Method | Supports national standard AC charging / wireless charging / automatic charging |
| Drive Motor (kW) | 5 |
| Braking System | Front disc, rear disc + hydraulic brake |
| Parking System | EPB electronic parking brake |
| Suspension System | Front and rear multi-link + rigid axle |
| Upper Power Supply | 12V DC-DC (24V available upon request) |
