Asphalt Pavement Hot Regeneration Repair Truck Hgy5142txbj6-1

Description

HGY5142TXBJ6-1 (hot air type) asphalt pavement hot regeneration repair truck is mainly used for asphalt pavement pothole repair, improve the smoothness of the road surface and driving comfort, improve road safety, is a multi-purpose asphalt pavement repair equipment.

The equipment can realise the regeneration of asphalt pavement waste material, cold material and milling material, and can also mix the new material (asphalt and aggregate) into asphalt concrete for use; it has the functions of asphalt spraying, waste recycling, power output, etc.; equipped with independently researched and developed dust removal system, which is green and environmental protection; it is suitable for daily maintenance of asphalt pavements of various grades

Product Features :

● The recycled mixing silo adopts rotary rolling structure and hot air circulation heating system, with high heating efficiency, no segregation, no sticking wall and fast discharging speed.

● The hot asphalt system is equipped with imported diesel burner, and the asphalt pipeline is heated by electricity, which is heat preservation and cleaning free.

● Dedusting system can effectively remove asphalt smoke, dust, etc. produced during the use of the process to reduce air pollution.

● Waste bin, tool box, water tank and other auxiliary devices to meet the needs of a variety of construction conditions.

● Equipped with electric and hydraulic power output interface, providing power for a variety of auxiliary equipment.

1

Parameters
Product NameAsphalt pavement hot regeneration repair vehicle
Product ModelHGY5142TXBJ6-1
Emission standardCountry VI
Generator power5kW
Regeneration mixing silo capacity1000kg
Dust removal deviceCyclone Dust Collector
Asphalt tank capacity1000L
Production capacity3-5t/h
Asphalt tank burner power10x10kcal/h
Hot air furnace burner power20x10kcal/h
Total mass14060kg
Overall Dimension8290x2480x3250mm
