Haowo 12-ton foam fire truck

Haowo 12-ton foam fire truck

(Vehicle model: CLW5280GXFPM120/HW type foam fire truck)

(Chassis model: ZZ5357TXFV464MF5)

I. Cab

Structure: Flat front, original double-row seat, four-door passenger compartment.

Seat configuration: 2 people in the front row, 4 people in the rear row.

Guardrails and handrails are installed in front of the seats. Firefighters quickly carry air respirators during the journey to the fire scene and quickly engage in firefighting and rescue operations upon arrival at the fire site.

Cab structure: Equipped with a hydraulic flip mechanism suitable for overturning.

Cab equipment: In addition to the original vehicle equipment, additional components include an engine puller control switch, a 100W alarm, and a warning light switch.

Cab exterior: At the front of the cab, a long row of warning lights is installed.

II. Tanks

Capacity: Water: 9000 Kg, Foam: 3000 Kg

Material: Water tank: High-quality steel plate, treated with advanced anti-corrosion technology

Foam tank: High-quality 304# stainless steel

Structure: Welded frame, longitudinal and transverse shock-absorbing plates are set inside the tank to reduce the impact of water inside the tank on the tank body during vehicle movement; The front and rear wall panels of the tank are folded with trapezoidal reinforcing ribs, giving the tank sufficient strength and rigidity.
