RV Kunpeng Shuangtuo Enjoy Edition

Extra large space to accommodate running up the mountain and the sea

2.15*1.58m large forehead bed

With heightened and widened 2.19 * 1.36m after the bed 45D high rebound composite mattress soft and hard moderate, suitable for Chinese people's sleep habits

Easily meet the needs of a family of five traveling

1.1m×0.6m extended kitchen table

Make cooking easy

15 storage spaces in the whole car, with up to 1100L of storage space outside the car.

Easily fit a family's life

Curved roof in the center roof to protect the roof from water accumulation

3.3m customized awning + drying hooks

Lighted armrests, hollow acrylic windows can enjoy the warmth of home even when you are out and about. Flat locking hatch, center locking passenger door, the whole car is fitted with a key for universal use.

Every "small ideas" know what you need

10 degrees of electricity + 700W solar battery (maximum optional 1100W) 3kW utility charging and 150A running generator

With AC new energy charging device multiple ways to say goodbye to electricity anxiety

220L water tank + 70L gray water tank

Guard the family's water freedom

Sentry mode, vehicle status monitoring and alarm 4G high-speed wifi, unlimited current and speed (optional)

Let the joy and convenience go with you

10kW plateau version of automatic thermostatic heater can be used at 4000m altitude.

DC inverter air-conditioning for RVs to avoid excess power loss and heat generated by inverter.

Honeycomb thermal insulation technology 41mm thick laminate floor, 32mm thick side wall compartment internal aluminum frame + PVC keel cold bridge structure without fear of high temperature and high cold.

Enjoy traveling freely

Version：240325-ZK5052XLJC6(Left side semi-expansion rear semi-expansion layout, enjoyable version)

Basic Parameters Length(mm) 5995 Fuel Diesel Emission Standard National 6

Width (mm) 2530 Fuel tank capacity (L) 80 Rated passenger capacity (persons) 6

Height(mm) 3110 Front/Rear Overhang(mm) 1023/1612 Maximum Speed km/h 155

Cabin height(mm) 2015 Wheelbase(mm) 3360 Wheelbase front/rear(mm) 1740/1750

Minimum Turning Diameter(m) 13.7 Total Quality(kg) 4120,4260,4475

Minimum Ground Clearance(mm) 190 Maximum Gross Mass(kg) 5250

Engine position front Approach/departure angle (°) 20/13

Displacement(L) 2.296 Chassis Manufacturer Jiangling Motors Co.
